Friday, January 9, 2015

Unity 4.6: Creating a look-based GUI for VR

In a previous post, I talked about creating GUIs for VR using world space canvases. In that example,   the GUI only displayed text - it didn't have any input components (buttons, sliders, etc). I wanted to add a button above each thought bubble the user could click to hear the text read aloud.

As I had used a look-based interaction to toggle the visibility of the GUI, this brought up the obvious question of how do I use a similar interaction for GUI input?  And, importantly,  how do I do it in a way that takes advantage of Unity's GUI EventSystem?

Turns out, what's needed is a custom input module that detects where the user is looking. There is an excellent tutorial posted on the Oculus forums  by css that is a great place to start. That tutorial includes the code for a sample input module and walks you through the process of setting up the GUI event camera.  (You need to assign an event camera to each canvas and one twist is that the OVR cameras don’t seem to work with the GUI.) By following that tutorial, I was able to get look-based input working very quickly.

Note that while look-based interactions are immersive and fairly intuitive to use, it is worth keeping in mind that look-based input won’t work in all situations. For example, if you have attached the GUI to CenterEyeCamera  to ensure that the user always sees the GUI, the GUI will follow the user’s view meaning the user won’t be able to look at any one specific option.

Friday, December 12, 2014

Unity 4.6: Thought bubbles in a Rift scene using world space canvases

I’m really liking the new GUI system for 4.6. I had been wanting to play a bit with a comic-book style VR environment and with world space canvases,  and now is the time.


Here's a quick rundown of how I created the character thought bubbles in this scene using world space canvases.

Creating world space canvases

Canvases are the root object for all Unity GUI elements. By default they render to screen space but you also have the option of rendering the canvas in world space, which is exactly what you need for the Rift. To create a canvas, from the Hierarchy menu, select Create > UI > Canvas. When you create a canvas, both a Canvas object and an Event System object are added to your project. All UI elements need to be added as children of a Canvas. Each thought bubble consist of world-space Canvas, and two UI elements - an image and a text box. For organization, I put the UI elements in an empty gameObject called ThoughtBubble.

Note. Hierarchy order is important as UI objects are rendered in the order that they appear in the hierarchy.

To have the canvas render as part of the 3d scene, in the Inspector for the Canvas, set the Render Mode to World Space.

When you change the render mode to world space, you’ll note that the Rect Transform for the canvas becomes editable. Screen space canvases default to the size of the screen, however, for world space canvases you need to set the size manually to something appropriate to the scene.

Setting canvas position, size, and resolution

By default the canvas is huge. If you look in the Inspector, you'll see that it has Width and Height properties as well as Scale properties.  The height and width properties are used to control the resolution of the GUI.  (In this scene the Width and Height are set to 400 x 400. The thought bubble image is a 200 X 200 px image and the font used for the Text is 24pt Ariel.)  To change the size of the canvas you need to set the Scale properties.

To give you an idea of the proportions, the characters in the scene are all just under 2 units high. and the scale of each canvas is set to 0.005 in all directions.  With the canvas a reasonable size, I positioned each canvas just above the character.

Rotating the canvas with the player's view

For the thought bubble to be read from any direction, I attached a script to the Canvas to set the canvas transform to look at the player .

using UnityEngine;
using System.Collections;

public class lookatplayer : MonoBehaviour {
    public Transform target;
    void Update() {

Toggling canvas visibility

When you look at a character the thought bubble appears. The thought bubble remains visible until the you look at another character. There were two ways I looked at for toggling the menu visibility - setting the active state of the UI container gameObject (ThoughtBubble) or adding a Canvas Group component to the UI container gameObject and setting the Canvas Group's alpha property. Changing the alpha property seemed easier as I would not need to keep track of inactive gameObjects, so I went with that method.   There is a canvas attached to each character in the scene. The script below is attached to the CenterEyeObject (part of the OVRCameraRig prefab in the Oculus Integration package v. 0.4.4). It uses ray casting to detect which person the user is looking at and then changes the alpha value of the character's attached GUI canvas to toggle the canvas visibility.

using UnityEngine;
using System.Collections;

public class lookatthoughts : MonoBehaviour {
    private  GameObject displayedObject = null;
    private  GameObject lookedatObject  = null;

    // Use raycasting to see if a person is being looked
    // at and if sodisplay the person's attached gui canvas
    void Update () {
        Ray ray = new Ray(transform.positiontransform.forward);
        RaycastHit hit;

        if(Physics.Raycast(rayout hit100)) {
            if (hit.collider.gameObject.tag == "person"){
                lookedatObject = hit.collider.gameObject;
                if (displayedObject == null){
                    displayedObject = lookedatObject;
                }else if (displayedObject == lookedatObject){
                    //do nothing
                    displayedObject = lookedatObject;

    // Toggle the menu display by setting the alpha value
    // of the canvas group
    void changeMenuDisplay(GameObject menufloat alphavalue){

        Transform tempcanvas = FindTransform(menu.transform"ThoughtBubble");

        if (tempcanvas != null){
            CanvasGroup[] cg;
            cg = tempcanvas.gameObject.GetComponents<CanvasGroup>();
            if (cg != null){
                foreach (CanvasGroup cgs in cg) {
                    cgs.alpha = alphavalue;

    // Find a child transform by name
    public static Transform FindTransform(Transform parentstring name)
        if ( return parent;
        foreach (Transform child in parent)
            Transform result = FindTransform(childname);
            if (result != nullreturn result;
        return null;

Wednesday, November 12, 2014

Unity 4: Knowing which user profile is in use

Previous versions of the Unity Integration package did not include a call for getting the user profile name. As of 0.4.3, it is now possible get the the user profile name. To know which profile is being used, you can use GetString()found in the OVRManager.cs script.

public string GetString(string propertyName, string defaultVal = null)

Below is a simple example script (report.cs) that uses this method to print out the name of the current user profile to the console. To use this script,  attach it to an empty game object in a scene that is using the OVRCameraRig or OVRPlayerController prefab. With the Rift connected and powered on, run the scene in the Unity Editor. If default is returned, no user profile has been found.

using UnityEngine;
using System.Collections;
using Ovr;

public class report : MonoBehaviour {
    void Start () {
     Debug.Log (OVRManager.capiHmd.GetString(Hmd.OVR_KEY_USER, "")) 

The GetString()method found in the OVRManager.cs script method is used to get the profile values for the current HMD. The OVRManager.cs script gets a reference to the current HMD, capiHmd. The Hmd class, defined in OvrCapi.cs, provides a number of constants that you can use to get user profile information for the current HMD. In this example, I used OVR_KEY_USER to get the profile name. You could also get the user’s height (OVR_KEY_PLAYER_HEIGHT), IPD (OVR_KEY_IPD) or gender (OVR_KEY_GENDER), for example.

Thursday, November 6, 2014

Thoughts on an alternative approach to distortion correction in the OpenGL pipeline

Despite some of the bad press it's gotten lately, I quite like OpenGL.  However, it has some serious limitations when dealing with the kind of distortion required for VR.

The problem

VR distortion is required because of the lenses in Ouclus Rift style VR headsets.  Put (very) simply, the lenses provide a wide field of view even though the screen isn't actually that large, and make it possible to focus on the screen even though it's very close to your eyes.

However, the lenses introduce curvature into the images seen through them.  If you render a cube in OpenGL that takes up 40° of your field of view, and look at it through the lenses of the Rift, you'll see curvature in the sides, even though they should be straight.

In order to correct for this, the current approach to correction is to render images to textures, and then apply distortion to the textures.  Think of it as painting a scene on a canvas of latex and then stretching the latex onto a curved surface.  The curvature of the surface is the exact inverse of the curvature introduced by the lenses, so when you look at the result through the lens, it no longer appears distorted.

However, this approach is extremely wasteful.  The required distortion magnifies the center of the image, while shrinking the outer edges.  In order to avoid loss of detail at the center, the source texture you're distorting has to have enough pixels so that at the area of maximum magnification, there is a 1:1 ratio of texture pixels to screen pixels.  But towards the edges, you're shrinking the image, so all your extra rendered pixels are essentially going to waste.  A visual representation of this effect can be seen in my video on dynamic framebuffer scaling below, at about 1:12.

A possible solution...

So how do we render a scene with distortion but without the cost of all those extra pixels that never make it to the screen?  What if we could modify the OpenGL pipeline so that it renders only the pixels actually required?

The modern OpenGL pipeline is extremely configurable, allowing clients to write software for performing most parts of it.  However, one critical piece of the pipeline remains fixed: the rasterizer.  During rendering, the rasterizer is responsible for taking groups of normalized devices coordinates (where the screen is represented as a square with X and Y axes going from -1 to 1) representing a triangle and converting them to lists of pixels which need to be rendered by the fragment shaders.  This is still a fixed function because it's the equivalent of picking 3 points on a piece of graph paper and deciding which boxes are inside the triangle.  It's super easy to implement in hardware, and prior to now there hasn't been a compelling reason to mess with it.

But just as the advent of more complex lighting and surface coloring models made the fixed function vertex and fragment shaders in the old pipeline led to the rise the current model, the needs of VR give us a reason to add programmability to the rasterizer.

What we need is a way to take the rasterizers traditional output (a set of pixel coordinates) and displace them based on the required distortion.

What would such a shader look like?  Well, first lets assume that the rasterizer operates in two separate steps.  The first takes the normalized devices coordinates (which are all in the range [-1,1] on both axes) and outputs a set of N values that are still in normalized devices coordinates.  The second step displaces the output of the first step based on the distortion function.

In GLSL terms, the first step takes three vec3 values (representing a triangle) and outputs N vec3 coordinates.  How many N depends on how much of the screen the triangle covers and also the specific resolution of the rasterization operation.  This would not be the same resolution as the screen for the same reason that we render to a larger than screen resolution texture in the current distortion method.  This component would remain in the fixed function pipeline.  It's basically the same as the graph paper example, but with a specific coordinate system.

The second step would be programmable.  It would consist of a shader with a single vec2 input and a single vec2 output, and would be run for every output of the first step (the vec3's become vec2's because at this point in the pipeline we aren't interacting with depth, so we only needs the xy values of the previous step).

in vec2 sourceCoordinate;
out vec2 distortedCoordinate;

void main() {
  // Use the distortion function (or a pre-baked structure) to
  // compute the output coordinate based on
  // the input coordinate

Essentially this is just a shader that says "If you were going to put this pixel on the screen here, you should instead put it here".  This gives the client the displace the pixels that make up the triangle in exactly the same way they would be displaced using the texture distortion method currently used, but without the cost of running so many extra pixels through the pipeline.

Once OpenGL has all the output coordinates, it can map them to actual screen coordinates.  Where more than one result maps to a single screen coordinate, OpenGL can blend the source pixels together based on each's level of contribution, and send the results as a single set of attributes to the fragment shader.

The application of such a rasterization shader would be orthogonal to the vertex/fragment/geometry/tesselation shaders, similar to the way compute shaders are independent.   Binding and unbind a raster shader would have no impact on the currently bound vertex/fragment/geometry/tesselation shader, and vice versa.

Chroma correction

Physical displacement of the pixels is only one part of distortion correction.  The other portion is correction for chromatic aberration, which this approach doesn't cover.

One approach would be to have the raster shader output three different coordinates, one for each color channel.  This isn't appealing because the likely outcome is that the pipeline then has to run the fragment shader multiple times, grabbing only one color channel from each run.  Since avoiding running the fragment shader operations more than we have to is the whole point of this exercise, this is unappealing.

Another approach is to add an additional shader to the program that specifically provides the chroma offset for each pixel.  In the same way you must have both a vertex and a fragment shader to create a rendering program in OpenGL, a distortion correction shader might require both a raster and a chroma shader.  This isn't ideal, because only the green channel would be perfectly computed for the output pixel it covers, while the red and blue pixels would be covering either slightly more or slightly less of the screen than they actually should be.  Still it's likely that this imperfection would be well below the level of human perception, so maybe it's a reasonable compromise.


You want to avoid situations where two pixels are adjacent in the raster shader but the outputs have a gap between them when mapped to the screen pixels.  Similar to the way we use a higher resolution than the screen for textures now, we would use a higher resolution than the screen for the rasterization step, thus ensuring that at the area of greatest magnification due to distortion, no two two adjacent input pixels cease to be adjacent when mapped to actual physical screen resolution

An unavoidable consequence of distortion, even without the above resolution increase is that pixels that are adjacent in the raster shader inputs will end up with their outputs mapping to the same pixel.

Depending on the kind of distortion required for a given lens, the calculations called for in the raster shader might be quite complex, and certainly not the kind of thing you'd want to be doing for every pixel of every triangle.  However, that's a fairly easy problem to solve.  When binding a distortion program, the OpenGL driver could precompute the distortion for every pixel, as well as precompute the weight for each rasterizer output pixel relative to the physical screen pixel it eventually gets mapped to.  This computation would only need to be done once for any given raster shader / raster raster resolution / viewport resolution required.  If OpenGL can be told about symmetry even more optimization is possible.

You end up doing a lot more linear interpolation among vertex attributes during the rasterization state, but all this computation is still essentially the same kind of work the existing rasterization stage already does, and far less costly than a complex lighting shader executed for a pixel that never gets displayed.

Next steps

  • Writing up something less off the cuff
  • Creating a draft specification for what the actual OpenGL interface would look like
  • Investigating a software OpenGL implementation like Mesa and seeing how hard it would be to prototype an implementation
  • Pester nVidia for a debug driver I can experiment with
  • Learn how to write a shader compiler
  • Maybe figure out some way to make someone else do all this

Wednesday, October 22, 2014

Video: Rendering OpenCV captured images in the Rift

In this video, Brad gives a walkthrough of an application that pulls images from a live Rift-mounted webcam and renders them to the display.

Links for this video:

Tuesday, October 14, 2014

Using the DK 2 on a MacBook Pro

Updated this information elsewhere so updating it here, too. Here is what I did to get the DK 2 running on the MacBook Pro.

I first downloaded the 0.4.1 SDK and Runtime for the Mac. I then plugged in all cables as recommended in the guide that comes with the DK 2. After getting the cables set up, I installed the Runtime and SDK. The README contains this note:

 “Before using your new DK2, it is critical to update the firmware on the headset. This is important to ensure reliable functioning of your DK2. Use the Config Util to install the firmware file supplied in this release (v2.11). This is only relevant to DK2 owners.”

As I had tested the DK2 out on Windows previously, I had already updated my DK2 firmware to 2.11. Just to be sure, I ran OculusConfigUtil and confirmed that my firmware was up-to-date. While I had it open, I went ahead and created a user profile for myself. Creating a profile can help prevent discomfort when using the Rift.
OculusConfigUtil profile screen

On Windows, there is the new Direct HMD Access display mode which can be set by selecting Tools > Rift Display Mode in the OculusConfigUtil menu. At this time, Direct HMD Access mode is not supported on the Mac.

OculusConfigUtil Display modes selection panel
So for the Mac, the next step is to configure the displays. As with earlier releases, you have the choice of using Extended mode and Mirrored mode. Previously, I had not been able to get Extended mode to work and was forced to use mirroring. Oculus recommends against mirroring, so I gave Extended mode another try.

Extended Mode

In the display preference, I set the displays to extended mode. My laptop screen was set as the main display and the Rift was the extended display.  The Unity Integration guide, in the monitor set up section, says “For DK2, the resolution should be Scaled to 1080p, the rotation should be 90°and the refresh rate  should be 75 Hertz,” so those were the settings I used.

In the OculusConfigUtil I then selected Show Demo Scene and the demo scene appeared correctly on the Rift. Yeah!

The desk scene demo accessed by selecting the "Show Demo Scene" button in OculusConfigUtil

I then tried to run the “Oculus World Demo" and it appeared on my main monitor and not the Rift. The mouse cursor also disappeared so there was no way to move the demo window to the extended portion of the desktop. The Unity Integration guide monitor set up section says “Some Unity applications will only run on the main display. In the Arrangement screen, drag the white bar onto the Rift's blue box to make it the main display.” This was the case with the “Oculus World Demo"  and to view it I needed to set the Rift as the main display and then run the demo.  But, doing so wasn’t as simple as it sounds.

Working with the desktop is not really possible when looking through the Rift, so I needed to first make sure the “Display Preferences Window” and the finder window with the application I wanted to launch were situated such that they were at least partially on the extended portion of the display before I switched to having the  Rift be the main display.

Desktop window positioning

With these windows in place, in the “Display Preferences Window” I grabbed the white bar that indicates which display is the main display and dragged it so that the Rift was now the main display.

You need to grab the white bar that indicates which display is the main display and drag it so that the Rift is main display.

Then with my main screen as the extended display, I double clicked on the “Oculus world demo” to run it.

And the demo ran successfully on the Rift.

That process was very cumbersome, so I decided to also take a look at using mirrored mode.

Mirrored Mode

In the display preferences, I set the displays to mirrored. Again, I needed to rotate the display 90 degrees for the display to be the correct orientation.

I then ran both the “Oculus World Demo” and the demo in the config Utility. In both cases I saw a lot of judder as I moved my head around (very headache inducing). The release notes have this to say on the topic:

“ Scene Judder - The whole view jitters as you look around, producing a strobing  back-and-forth effect. This effect is the result of skipping frames (or Vsync)  on a low-persistence display, it will usually be noticeable on DK2 when frame rate falls below 75 FPS. This is often the result of insufficient GPU performance or attempting to render too complex of a scene. Optimizing the engine or scene content should help.
We expect the situation to improve in this area as we introduce asynchronous timewarp and other optimizations over the next few months. If you experience this on DK2 with multiple monitors attached, please try disabling one monitor to see if the problem goes away.”

On a suggestion from Brad, I tried setting the display refresh rate to 60 hertz. This significantly reduced the judder; however, there was noticeable screen blur when I moved my head. The good news on the blur was that unlike the judder, it wasn’t an immediate headache trigger for me.

Which mode will I use?

Which mode I will use will really depend on what I am trying to do.  If I am just using the Rift,  I would choose extended mode  as it does offer better performance. In extended mode I was seeing 75 FPS and in mirrored mode with the refresh rate set to 75 hertz I was seeing 46 FPS and with the refresh rate set to 60 I was seeing 60 FPS.

But until Direct HMD Access mode works on the Mac, unless I am testing for performance, I will probably mostly use mirrored mode when developing.  Mirrored mode allows me to see what the person using the Rift is doing and provides a faster work-flow for doing quick iterations.

Wednesday, October 1, 2014

Video: Dynamic Framebuffer Scaling in the Oculus Rift

In this video Brad discusses dynamic framebuffer scaling in the Oculus Rift:

 Links from the video:
